Accessories

[PN: 135-1000] Link ECU Razor PDM

Click here for the PDM Knowledge Base which includes the specifications sheet and user manual. DETAILS: Link's highly anticipated PDM, the Razor PDM, is an intelligent Power Distribution Module that replaces traditional fuses and relays,...

[PN: 101-0054] Link ECU Knock Sensor with Loom (KNSB)

DETAILS:   Donut style 8mm Knock Sensor prewired with 2.6m loom, flying leads.  Suitable to wire directly to Link ECU or use with the G4 Knocklink Visual Warning Light.

[PN: 101-0053] Link ECU Knock Sensor (KNS)

DETAILS: Donut style 8mm hole Includes plug and pin kit

[PN: 114-2000] Link ECU G4 KnockLink Kit - Includes Knock Sensor+Loom (G4KNLK)

DETAILS:   Kit includes the G4 KnockLink visual warning light and a knock sensor with loom. The KnockLink is a self-calibrating, visual knock warning tool. This kit is designed for tuning, street and race use.The G4 KnockLink is the only...

[PN: 114-1000] Link ECU KnockLink G4 (G4KNL)

DETAILS:   KnockLink is a self-calibrating, visual knock warning tool. The KnockLink is designed for tuning, street and race use. Will require a knock sensor to function (sold separately) or you can purchase the KnockLink Kit that includes the...

[PN: 105-1000] Link ECU KnockBlock G4+ (KNB)

DETAILS:   The G4+ KnockBlock is an essential tool for tuning and can aid in the early detection of incorrect ignition timing, lean air/fuel mixtures and mechanical issues. It is used it with ear buds, headphones or noise cancelling ear muffs and...

[PN: 110-0005] Link ECU Mounting bracket for G4+ & G4X Atom & Monsoon (MTB2)

[PN: 100-0113] Link ECU Mounting bracket for G4+ & G4X Fury, Xtreme, Storm, Force (MTB1)

[PN: 101-0016] Link ECU Boost Control Solenoid - 4 Port (4BCS)

DETAILS:   Thinking of turning up the boost to max? Then this 4 port boost control solenoid is perfect. It allows for precise boost control of up to 120PSI.4 port Boost control soldenoids are commonly used for big boost applications,...

[PN: 101-0103] Link ECU Trigger Wheel (TWS)

DETAILS:   Small Diameter Trigger wheel – Medium and Large sizes also available.  24 tooth 150mm diameter 40mm centre

[PN: 101-0102] Link ECU Trigger Wheel (TWM)

DETAILS:   Medium Diameter Trigger wheel – Small and Large sizes also available. 24 tooth 175 diameter 40mm centre

[PN: 101-0101] Link ECU Trigger Wheel (TWL)

DETAILS:   Large Diameter Trigger wheel – Small and Medium sizes also available. 60-2 tooth 200mm diameter 40mm centre

[PN: 101-0014] Link ECU Ballast Resistor (BAL6)

DETAILS:   For use with low-impedance injectors. Compatible with injectors with impedance between 2 and 6 Ohms. Please contact us if you are planning on using injectors with an impedance of less than 2 ohms.  Includes set of 6 x 4.7ohm...

[PN: 101-0013] Link ECU Ballast Resistor (BAL4)

DETAILS:   For use with low-impedance injectors. Compatible with injectors with impedance between 2 and 6 Ohms. Please contact us if you are planning on using injectors with an impedance of less than 2 ohms. Includes set of 4 x 4.7ohm...

[PN: 101-0012] Link ECU Ballast Resistor (BAL2)

DETAILS: For use with Low-Impedence Injectors. Includes set of 2 x 1 Ohm 50w resistors mounted to a heatsink. These are also sold in a single pack. Please contact us to ensure compatibility with your injectors.

[PN: 101-0011] Link ECU Ballast Resister (BAL)

DETAILS:   For use with Low-Impedence Injectors. Includes a single 1 Ohm 50W resistor mounted to a heatsink. Please contact us to ensure compatibility with your injectors.

[PN: 101-0291] Link ECU IGN1A - High Powered Inductive Smart Coil (Integrated Ignitor)

Link to User Guide     DETAILS:   High Power Inductive Coil with built-in ignitor. Produce 103 mJ per spark, with a longer spark duration (2.9 ms) than what you’d see with a capacitive discharge Built-in ignitor with...

[PN: 101-0044] Link ECU Three Channel Inductive Igniter (I3)

DETAILS:   This three channel igniter is suitable for electronic ignition applications.  Required when using coils that don't have inbuilt igniters.Common uses include: wasted spark on 6 cylinder engines, coil-per-plug setups on 3...

[PN: 101-0280] Link ECU Hall Effect Sensor Kit

DETAILS:   Hall effect sensor designed for use in applications where ferrous edge detection/near zero speed sensing is needed. They provide a sinking current output. Typical automotive applications include: Crank & Cam...

[PN: 101-0025] Link ECU Crank Angle Sensor (CAS)

DETAILS:   Used in conjunction with a trigger wheel to measure crank angle, a vital measurement for engine operation. Can be used with almost any steel trigger wheel, see related products for our trigger wheel options...

[PN: 101-0100] Link ECU Throttle Position Sensor (TPSCW/CCW)

DETAILS:   Throttle Position Sensor. Supports clockwise and counter-clockwise installations. 6 wire flying lead.  Wiring instructions are provided in the box. FEATURES: 8 mm D-Shaft Rotary Sensor Hall Effect non-contact...

[PN: 101-0146] Link ECU Exhaust Gas Temperature Probe (EGT)

DETAILS:   Extreme Duty Fast Response EGT Temperature Probe  Type K thermocouple probe Exposed sensing junction for fastest response Includes 316 SS adjustable compression fitting Stainless steel protected wires Designed for extreme...

[PN: 101-0034] Link ECU Ethanol Content Sensor (ECS)

DETAILS:   Looking to run flex-fuel? Then the Ethanol Content Sensor is a must have. The Ethanol Content Sensor measures the ratio of ethanol to petrol in a flex fuel vehicle. This sensor also measures fuel temperature. Compatible with all...

[PN: 101-0077] Link ECU Coolant Temperature Sensor (NTC12)

DETAILS: Includes Plug Kit - 2 way Bosch Style plug, terminals and boot M12 Thread

[PN: 101-0076] Link ECU Coolant Temperature Sensor (NTC1-8)

DETAILS: Includes 2-pin Deutsch DTM connector kit Aluminium and steel weld in mounting bosses available 1/8" NPT Thread

[PN: 101-0050] Link ECU Mounting Boss Steel (IATBMS)

DETAILS:   Weld in Steel Boss. Bosch part. Suitable for mounting the IATB Inlet Air Temperature sensor and other sensors that mount via a Bosch style flange.

[PN: 101-0049] Link ECU Mounting Boss Aluminium (IATBMA)

DETAILS:   Weld in Aluminium Boss. Bosch part. Suitable for mounting the IATB Inlet Air Temperature sensor and other sensors that mount via a Bosch style flange.

[PN: 101-0048] Link ECU Air Temperature Sensor (IATB)

DETAILS: Includes Plug Kit - 2 way Bosch Style plug, terminals and boot Aluminium and steel weld in mounting bosses available (IATBMA & IATBMS)

[PN: 101-0047] Link ECU Mounting Boss Steel (IAT1-8MS)

DETAILS:   Weld in steel boss, 1/8" NPT Thread. Suitable for mounting Intake air temperature (IAT1-8), Coolant Temperature sensors (NTC1-8) and other sensors that use 1/8" NPT Thread.

[PN: 101-0046] Link ECU Mounting Boss Aluminium (IAT1-8MA)

DETAILS:   Weld in Aluminium boss, 1/8" NPT Thread. Suitable for mounting Intake air temperature (IAT1-8), Coolant Temperature sensors (NTC1-8) and other sensors that use 1/8" NPT Thread.

[PN: 101-0045] Link ECU Air Temp Sensor (IAT1-8)

DETAILS: Includes 2-pin Deutsch DTM connector kit Aluminium and steel weld in mounting bosses available 1/8" NPT Thread

[PN: 101-0199] Link ECU Adapter M10 x 1 Female to 1/8 BSP Male

DETAILS:   Stainless Steel thread adapter, M10 x 1 Female to 1/8 BSP Male, Adapts popular Bosch Metric Pressure Sensors to suit 1/8 BSP threaded ports.

[PN: 101-0193] Link ECU Adapter M10 x 1 Female to 1/8 NPT Male

DETAILS:   Stainless Steel thread adapter, M10 x 1 Female to 1/8 NPT Male, Adapts popular Bosch Metric Pressure Sensors to suit 1/8 NPT threaded ports.

[PN: 101-0186] Link ECU 140 Bar Pressure Sensor (HPS)

Technical Specs:Up to 2030 PSI above atmospheric pressure, cannot be used to read vacuumSee attached image for more.    DETAILS: High Pressure sensor for Liquid. Use for Fuel, Clutch, Brake etc. 140 Bar/2030PSI 45degree cone...

[PN: 101-0080] Link ECU Pressure Sensor (PS150)

DETAILS: Oil or Fuel pressure 10 Bar/150psi 1/8” NPT Thread Includes plug and pin kit Technical Specs and WiringUp to 150 PSI above atmospheric pressure, cannot be used to read vacuum0.5v = 0bar / 0PsiG4.5v = 10 Bar / 145...

[PN: 101-0320] Link ECU Combined Pressure and Temperature Sensor (CPTS)

Technical Specs: See attached image.    DETAILS:   Two sensors in one - Combined 10 bar (145 psi) Liquid Pressure sensor and -40 to 140 deg C L Liquid Temperature sensor. Suitable for Oil, Coolant, Fuel, Transmission fluid etc. Up...
