[PN: 521001] Harmonic Balancer - Fluidampr - Mazda - 1993-2005 - MX5 Miata

MSRP: $597.00
$507.45
( saved $89.55 )
Write a Review
Adding to cart… The item has been added
SKU:
521001
Shipping:
Calculated at Checkout

Installation Instructions

1993-2005 Mazda MX5 Miata

Normal stock dampers wear out and engine performance upgrades increase naturally occurring harmful crankshaft torsional vibrations. Install a Fluidampr viscous damper to reduce wear on the main bearings and timing gear, achieve more accurate valvetrain operation and lower the risk of crank failure. Unlike rubber based dampers, Fluidampr automatically adapts to any engine modifications and constantly self-tunes in real time to protect across the entire RPM range. Features precision machined and computer balanced components that never need to be tuned or rebuilt.

PART # 521001
Fitment 1993 – 2005 Mazda MX-5 Miata
1992 – 1996 Mazda MX3 (1.6L I4 models)
1995 – 2003 Mazda Protégé 1.5L / 1.6L / 1.8L
Bore Diameter 1.064"
Degree Marking Range TDC.  10 deg reference mark.
Engine Balance Internal
Finish Black Zinc
Keyway Yes, 0.200"
Length 2.13"
Material Steel
Mounting Hardware Included Yes; 4x 12.9 grade M6 x 14mm bolts. Belt guide.
Outside Diameter 5-7/8"
Safety Rating SFI 18.1
Weight / Rotating Weight 7.2 lbs / 4.8 lbs
