Name: [PN: TS-0506-1002I] Turbosmart WG45 2011 Hypergate 45mm wastegate - 7psi Black-
SKU: TS-0506-1002
Price: 409.95 USD
Availability: InStock

[PN: TS-0506-1002I] Turbosmart WG45 2011 Hypergate 45mm wastegate - 7psi Black-

MSRP: $455.50

$409.95

( saved $45.55 )

Write a Review

Product Description

Installation guide

IT’S BACK. The Gen4 CompGate40 and HyperGate45 have been approved for continuation and re-introduction at an all-new price!

Still Australian-made!
Still a rock-solid performer!
Still, hand assembled and individually tested before shipping!
One change – A price drop!

Turbosmart is proud to announce the product continuation, re-introduction and price drop of their Gen4 CompGate40 and HyperGate45 external wastegates. This re-introduction with reduced pricing will help those of you who need a lower-spec solution but still want that Australian-made, hand-tested quality you get from a manufacturer with over 25 years of experience!

The Gen4 HyperGate45 is a 4th Generation external wastegate packed with value, performance and reliability! If you need a 45mm external wastegate and don’t have motorsport in mind, this is the solution for you! Genuine street performer with good flow & heat characteristics, which is suitable for pump fuel and e85 applications

Available in
Gen4 CompGate40 7 psi & 14 psi 40mm External Wastegate
Gen4 HyperGate45 7 psi & 14 psi 45mm External Wastegate

Features
V-Band inlet & outlet to suit 44/46mm peer fitment
Unique locking collar design
Stainless Steel cast body & Aluminium actuator housing
It can be fitted with springs from 3 to 26psi
Solid piece Stainless Steel valve
Proprietary high-temp silicon Nomex diaphragm
Twin 1/16″ NPT reference ports

SUPPLIED WITH

Gen4 external wastegate unit

Pre-fitted with springs as per description

Gen4 stainless steel valve seat

Gen4 V-band clamps

Gen4 inlet & outlet weld flanges

Locking collar tool

1/16″ NPT blanking plugs

1/16″ nipples (5mm)

SPARES

TS-0505-3006 Gen4 HyperGate45 Diaphragm Replacement

TS-0505-3009 Gen4 HyperGate45 1/16” NPT Fitting Kit

TS-0505-3013 Gen4 HyperGate45 Replacement Cap Black

TS-0504-3004 Gen4 HyperGate45 V-Band: Inlet

TS-0504-3005 Gen4 HyperGate45 V-Band: Outlet

TS-0504-3003 Gen4 HyperGate45 Valve Seat

TS-0504-3006 Gen4 HyperGate45 Valve & Guide Replacement

TS-0505-3007 Gen4 HyperGate45 Replacement Locking Collar

TS-0504-3001 Gen4 HyperGate45 Weld Flange: Inlet

TS-0504-3002 Gen4 HyperGate Weld Flange: Outlet

TS-0504-3007 Gen4 HyperGate45 Weld Flange: Inlet / Alloy

TS-0504-3008 Gen4 HyperGate45 Weld Flange: Outlet / Alloy

SPRINGS

TS-0505-2001 Gen4 HyperGate45 Spring 3psi Inner – Brown / Black

TS-0505-2002 Gen4 HyperGate45 Spring 5psi Inner – Brown / Grey

TS-0505-2003 Gen4 HyperGate45 Spring 7psi Middle – Brown / Purple

TS-0505-2004 Gen4 HyperGate45 Spring 11psi Middle – Brown / Red

TS-0505-2005 Gen4 HyperGate45 Spring 10psi Outer – Brown / Blue

TS-0505-2006 Gen4 HyperGate45 Spring 7psi Outer – Brown / Pink

ACCESSORIES

TS-0505-2008 1/16” NPT to -3AN Male to Male Adaptor

TS-0505-2009 1/16” NPT to -4AN Male to Male Adaptor

TS-0505-2007 1/16” NPT to 1/8” NPT Male to Female Adaptor

TOOLS

TS-0505-3008 Gen4 HyperGate45 Collar Tool

What is the first rule of boost control?

Set your boost cut limit. Mistakes happen, Failures occur, and the cheapest Insurance for any setup is ensuring you incorporate a careful setup boost cut limit. Unsure what this is or how to do that? Then we recommend reaching out for professional and qualified assistance.

Will this Wastegate fit my existing manifold?

Turbosmart External Wastegates are designed around peer flange orientation, meaning: Yes. If you have a 40mm valve, then our 40mm CompGage40 will fit & the same goes for the 45mm HyperGaet45, ProGate60 etc.

How do I change the spring(s)?

You will need the locking collar tool as supplied in the box. You also need to observe the instructions and apply pressure to the top cap before removing the collar – This is part of the design & an important anti-vibration measure.

What size are the reference fittings?

The reference ports are 1/16” NPT. We have a range of AN adapters and high temp push-lock fittings available in the Spares and Accessories Tab.

What am I doing wrong? The valve seat does not seem to sit flush to fit the clamps.

Your Turbosmart External Wastegate is designed to have pre-load, and you will need to push down & apply a small amount of force (the higher the base spring pressure, the higher the force) the get the V-band on. It is designed this way to ensure maximum seat pressure.

Why has my Wastegate housing changed Color?

Heat in your engine bay can affect the anodized finish of your wastegate; this does not necessarily mean it will ever affect performance or reliability. Engines & engine bays get extremely hot sometimes, and this discolouration can happen over time and use. Suppose it has happened particularly quickly, however. In that case, it may be worth looking at your setup and ensuring adequate airflow to the wastegate – There is a difference between use and abuse.

I cannot get control of the boost. What is wrong?

The number 1 issue with boost control is the reference/hookup method. Get back to basics: Try using the simplest hookup method (Boost Reference to the lower port of your actuator) and performing a power run. What boost did it make?

If you are making the boost the springs fitted would suggest, then the gate is working as expected, and you need to look at your hookup method and boost control strategy.

If you are making less boost, you must check for leaks in your pipework and hoses.

If you are making more boost, then you look at your manifold design for gate priority or the actual size of the gate you are using versus the bypass requirements.
