Name: [PN: TS-0553-1011] Turbosmart WG45 GenV Hyper-Gate 45mm wastegate - 14psi Blue
SKU: TS-0553-1011
Price: 444.95 USD
Availability: InStock

[PN: TS-0553-1011] Turbosmart WG45 GenV Hyper-Gate 45mm wastegate - 14psi Blue

MSRP: $494.39

$444.95

( saved $49.44 )

Write a Review

Product Description

Installation guide

Data sheet

The GenV WG45 HyperGate45 External Wastegate is a Motorsport-proven, cost-effective 45mm external wastegate – The highest flowing gate of its kind. The GenV provides extensive user configuration, world-leading extended thermal performance, fatigue resistance and best-in-class flow performance for optimum control and longevity.

The GenV External Wastegate from Turbosmart was a ground-up rework of a classic, and the only feature that rolled over from the Gen4 range was the mounting orientation. CFD is optimized and validated in-house for maximum flow and thermal management; the GenV Range has more features, options, and performance than any other gate.

A direct fit upgrade to all Gen4 Turbosmart wastegates and feature our unique collar-locking system, variable actuator cap and base for easy, 360-degree optional routing of reference hoses, strap-type Vband clamps, optional liquid-cooling provision, 1/8″ NPT reference ports and are provided with the full range of available springs.

Available In
Black, Blue, Red, Purple and Sleeper colours
Wastegate Position Sensor Optional Upgrade
Compressed Gas / Co2 Version
Motorsport / Extreme Temp Version
Electronically Actuated / eWG Version
High Pressure (Up to 50psi Base) Version

Features
Class Leading Thermal Performance
Class Leading CFD and Bench-Validated Flow Performance
Class Leading Fatigue Resistance
Optional Liquid Actuator Cooling
Optional Position Sensor Available Separately
Rotatable / Clockable Actuator Housing
Nitronic 60 Valve Guide and High Temp 347 SS Body
17-7 PH Stainless Steel Springs
Strap Type V-band clamps

SUPPLIED WITH
GenV Wastegate unit
All Springs Included
3.5.7.14psi (1 Inst. As per Description)
Locking Collar Tool
GenV SS316 Valve seat
Strap Type V-Bands
Inlet and Outlet Weld Flanges
Hose Tail and Blank Fitting Kit
Turbosmart Decal

SPARES
TS-0550-3005 GenV HyperGate45 Diaphragm Replacement
TS-0550-3010 GenV HyperGate45 Locking Collar
TS-0550-3014 GenV HyperGate45 Locking Collar Tool
TS-0550-3012 GenV HyperGate45 Slave Collar / Heatshield
TS-0553-3001 GenV HyperGate45 Valve Seat
TS-0553-3002 GenV HyperGate45 Valve Guide and Set
TS-0504-3001 GenV HyperGate45 Weld Flange: Inlet
TS-0504-3002 GenV HyperGate45 Weld Flange: Outlet
TS-0553-3003 GenV HyperGate45 V-Band: Inlet
TS-0552-3003 GenV HyperGate45 V-Band: Outlet
TS-0550-3080 GenV HyperGate45 V-Band Nuts

SPRINGS
TS-0550-3085 GenV HyperGate45 Spring 3PSI Inner - Orange
TS-0550-3086 GenV HyperGate45 Spring 5PSI Inner - Yellow
TS-0550-3087 GenV HyperGate45 Spring 7PSI Middle - Green
TS-0550-3088 GenV HyperGate45 Spring 14PSI Outer - Blue

ACCESSORIES
TS-0550-3024 GenV HyperGate45 Sensor Cap Black
TS-0550-3007 GenV Diaphragm Replacement Tool
TS-0504-3007 GenV HyperGate45 Weld Flange: Inlet (Alluminium)
TS-0504-3008 GenV HyperGate45 Weld Flange: Outlet (Alluminium)
TS-0550-3008 1/8NPT to 6mm Hose End Adaptor
TS-0550-3050 1/8NPT to -3AN Male to Male Adaptor
TS-0550-3051 1/8NPT to -4AN Male to Male Adaptor
TS-0550-3054 1/8NPT 90º Poshloc Fitting - Hi-Temp (1/4")
TS-0550-3055 1/8NPT T-Piece Pushloc Fitting - Hi-Temp (1/4")
TS-0550-3053 1/8NPT Straight Pushloc Fitting - Hi-Temp (1/4")
TS-0550-3056 Hi-Temp Pushloc Tubing 1/4" Black (3 Metres)
TS-0550-3094 GenV Wastegate Press / Spring Change Tool

What is the first rule of boost control?
Ensure you have an over-boost cut-out. This safety feature is built into all factory, aftermarket and programmable ECUs. Make sure it is set at a sensible and reasonable limit. Increasing the boost will put more load on your engine, and there is another tune-related factory you must always consider. If in any doubt, speak with a professional tuner/calibrator.

Can I use this on any turbocharged engine?
External Wastegates are used on vehicles fitted with turbochargers that do not have an internal wastegate actuator. In most instances, external wastegates are custom-fitted items and require modifications to the factory exhaust manifold or a custom / specifically manufactured manifold to suit an external wastegate.

What is a GenV Wastegate?
A GenV Wastegate is a 5th Generation External Wastegate from Turbosmart. Turbosmart released the GenV range at the SEMA Show in 2017 and used several features never before seen on a wastegate, including rotating actuator housing, ceramic isolators, multi-angle machined valve seats and interchangeable actuator housings.

Do I have to use the liquid cooling ports?
No. The GenV External Wastegate boasts several design features, which means it can tolerate higher temperatures for longer than its peers. The liquid cooling is there in case you wish to use it or are one of the few who need to.

Why Does the Actuator Housing Rotate?
So you can route your reference hoses any way you like. The GenV external wastegate range is designed with an infinitely clock-able actuator housing so that the shortest, most convenient, and most suitable (temperature, etc.) route can be set up for the reference lines.

How do I change the springs?
You will need the locking collar tool supplied in the box, and you will also need to apply physical force to the top cap of the actuator. Applying force counteracts the preload applied with these assembled in the diaphragm and is a product design feature. Attempting to unlock the collar without this force will likely damage the collar and the actuator.

What size are the reference ports?
1/8NPT. Both the liquid cooling and the boost control reference ports are 1/8NPT. The GenV External Wastegates are delivered with a full hose tail and blanking fitting kit, which will get you going; you’re welcome to use adaptors for AN or push lock fittings for more advanced installs.

This is ‘X’ psi, but I want to run a different boost than that – Which gate should I get?
The pressure rating in the description of a GenV external wastegate is the base mechanical pressure, and we include all other springs in the box. You have base mechanical spring options from 3psi up to 26psi. Note, however, that this is just the lowest the gate can be set for, and with manipulation of the reference signal via a boost controller, you can generally achieve 2-3X the base pressure.
