Radium Low Profile Swiveling Banjo Fittings

These banjo fittings have the ability to rotate 360 degrees, even after installation. They are an excellent option for 90-degree connections and are very low profile. Suitable for use in high pressure fuel and oil systems. Do not exceed 400 psi.

20-1000-0406 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0465 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0485 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0606 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0606 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0610B Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0665 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0685 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-06313 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-06375 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0806 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-0808 Installed Height (bottom of hex to top): 1.019in (25.9mm)

20-1000-0810 Installed Height (bottom installed surface to top): 1.121in (28.5mm)

20-1000-0885 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-08313 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-08375 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-1008 Installed Height (bottom of hex to top): 1.019in (25.9mm)

20-1000-1010 Installed Height (bottom installed surface to top): 1.121in (28.5mm)

20-1000-1012 Installed Height (bottom installed surface to top): 1.286in (32.7mm)

20-1000-1085 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-10313 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-10375 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-1085 Installed Height (bottom installed surface to top): 0.797in (20.2mm)

20-1000-101010 Installed Height (bottom installed surface to top): 1.121in (28.5mm)
