SAMSONAS Universal RWD Sequential Gearbox

This gearbox was designed from the beginning as a gearbox for all cars. As such, it has a variety of options and fittings to allow it to be adapted to just about any place you need a hyper-shifting sequential gearbox.

• • solid aluminium casing;
  • has a transfer or reduction gear;
  • torque rating up to 2000 ft lbs
  • special steel X300 clutch shaft;
  • straight cut teeth, 5 dogs design;
  • big range of different clutch shafts and bellhouses like for Nissan, Toyota, BMW, Ford, Mazda, Opel, Volvo, Honda, Subaru and etc;
  • dry weight 38 kg;
  • drift, drag, rally, rally raid, rally cross, circuit.

  GEAR RATIO

  Option 1

  	Option 2	Option 3	Option 4	Option 5	Option 6	Option 7
  I II III IV V VI	2,462 1,800 1,471 1,250 1,087 0,962	3,000 2,000 1,471 1,190 1,000 0,875	3,000  2,000 1,500 1,250 1,087 0,962	3,000  2,000 1,500 1,190 1,000 0,875	3,000  2,000 1,500 1,190  0,962 0,833	3,000  2,000 1,500 1,190  0,962 0,760	3,000  1,800 1,500 1,250 1,087 0,962

  Transfer/Reduction Gear ratios: 0,700 • 0,840 • 0,870 • 0,920 • 0,962 • 1,000 • 1,040 • 1,087 • 1,143 • 1,250 • 1,333
